Peltier Elements - Thermoelectric Modules

Găsiți o gamă largă de Peltier Elements - Thermoelectric Modules la Farnell România. Avem în stoc o selecție largă de Peltier Elements - Thermoelectric Modules, inclusiv produse noi și cele mai populare de la cei mai buni producători din lume, inclusiv: Multicomp Pro, European Thermodynamics, Marlow Industries, Wakefield Thermal & Cui / Partner Stock.

Producător

Transducer Function

No. of Stages

Cooling Power Pc

Power Rating

Current Max @ Diff Temperature Max

Voltage Max @ Diff Temperature Max

Length

Width

Depth

Temperature Difference Max

Product Range

Internal Resistance

Lead Wires

Ambalaj

Niciun filtru aplicat

0 Filtru (filtre) selectat(e)

			Preţ pentru		Cantitate

APHM-065-05-15	2519558 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 4.2 W 0.8 A 8.3 VDC 12mm x 11mm x 3mm	Each	1+ 297,940 lei 5+ 250,900 lei 10+ 216,660 lei 20+ 212,340 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	4.2W	4.2W	800mA	8.3VDC	12mm	11mm	3mm	74°C	APHC	-	150mm, UL-Style 1569, Unstripped
MPETH-071-14-15-S-H1	3267525 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 34 W 6.6 A 9.1 VDC 30mm x 30mm x 3.2mm	Each	1+ 138,020 lei 3+ 118,010 lei 10+ 107,140 lei 25+ 96,930 lei 100+ 92,510 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	34W	34W	6.6A	9.1VDC	30mm	30mm	3.2mm	-	MPETH	1.1ohm	UL-Style 1213, Unstripped
MP008855	3912318 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 600 mW 0.8 A 1.3 V 4.9 mm x 3.25 mm x 2.45 mm	Each	1+ 177,090 lei 3+ 151,430 lei 10+ 137,460 lei 25+ 124,410 lei 100+ 118,720 lei	Min.: 1 / Mult.: 1	-	1 Stage	600mW	-	800mA	1.3V	4.9mm	3.25mm	2.45mm	67°C	-	-	100mm, UL-Style 1569, PVC Insulated
MP008851	3912314 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 400 mW 1.4 A 0.8 V 4 mm x 3.2 mm x 3.8 mm	Each	1+ 227,030 lei 3+ 211,230 lei 10+ 197,410 lei 25+ 189,230 lei	Min.: 1 / Mult.: 1	-	1 Stage	400mW	-	1.4A	0.8V	4mm	3.2mm	3.8mm	89°C	-	-	UL-Style 1569, PVC Insulated
MCPE-071-10-13	1639748 Data Sheet RoHS	MULTICOMP PRO Peltier Cooler 19.1W	Each	1+ 178,970 lei 3+ 153,010 lei 10+ 138,940 lei 25+ 125,680 lei 100+ 119,990 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	19.1W	19.1W	3.9A	8.8VDC	20mm	20mm	3.6mm	74°C	MCPE	2.05ohm	100mm, UL-Style 1569, Unstripped
DT-AR-045-12	2466921 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Assembly Direct To Air 48.4 W 5.725 A 122mm x 160mm x 84mm	Each	1+ 1.301,650 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	-	48.4W	48.4W	5.725A	15VDC	122mm	160mm	84mm	-	DT-AR	-	-
APH-241-10-08-E	2466912 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 102 W 6 A 29.2 VDC 40mm x 40mm x 3.1mm	Each	1+ 327,250 lei 5+ 275,590 lei 10+ 238,000 lei 20+ 233,220 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	102W	102W	6A	29.2VDC	40mm	40mm	3.1mm	67°C	APH	-	100mm, UL-Style 1569, Unstripped
APH-127-10-20-S	2466917 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 20 W 2.3 A 15.4 VDC 30mm x 30mm x 4mm	Each	1+ 194,460 lei 5+ 163,780 lei 10+ 141,430 lei 20+ 138,580 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	20W	20W	2.3A	15.4VDC	30mm	30mm	4mm	68°C	APH	-	150mm, UL-Style 1569, Unstripped
APHC-12704-S	2484934 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 36 W 3.7 A 14.7 VDC 30mm x 34mm x 3.63mm	Each	1+ 219,150 lei 5+ 184,560 lei 10+ 159,410 lei 20+ 156,210 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	36W	36W	3.7A	14.7VDC	30mm	34mm	3.63mm	66°C	APHC	3.2ohm	100mm, UL-Style 1569, Unstripped
AR-AR-024-12	2466918 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Assembly Air To Air 23.8 W 3.825 A 100mm x 83mm x 117.6mm	Each	1+ 1.271,170 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	-	23.8W	23.8W	3.825A	15VDC	100mm	83mm	117.6mm	-	AR-AR	-	-
MPETH-127-10-13-S-H1	3267526 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 35 W 4 A 16 VDC 30mm x 30mm x 3.6mm	Each	1+ 175,310 lei 3+ 149,860 lei 10+ 136,090 lei 25+ 123,140 lei 100+ 117,500 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	35W	35W	4A	16VDC	30mm	30mm	3.6mm	72°C	MPETH	-	100mm, UL-Style 1569, Unstripped
MPETH-017-14-18-E-H1	3267516 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 6.8 W 5.1 A 2.2 VDC 15mm x 15mm x 3.65mm	Each	1+ 120,090 lei 3+ 92,710 lei 10+ 76,560 lei 25+ 69,550 lei 100+ 62,890 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	6.8W	6.8W	5.1A	2.2VDC	15mm	15mm	3.65mm	74°C	MPETH	0.35ohm	UL-Style 1213, Unstripped
MPDT-AR-050-8D	3267535 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Assembly Direct To Air 52.5 W 5 A 276mm x 133mm x 97.5mm	Each	1+ 585,720 lei 3+ 549,860 lei 10+ 489,860 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	-	52.5W	52.5W	5A	18VDC	276mm	133mm	97.5mm	-	DT-AR	-	-
MP-AR-AR-070-24	3267540 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Assembly Air To Air 57.2 W 4.8 A 230mm x 138.6mm x 125.7mm	Each	1+ 1.355,900 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	-	57.2W	57.2W	4.8A	24VDC	230mm	138.6mm	125.7mm	-	AR-AR	-	-
MPETH-127-10-15-E-H1	3267530 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 29 W 3.1 A 16 VDC 30mm x 30mm x 3.4mm	Each	1+ 197,460 lei 3+ 168,810 lei 10+ 153,260 lei 25+ 138,680 lei 100+ 132,380 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	29W	29W	3.1A	16VDC	30mm	30mm	3.4mm	72°C	MPETH	4ohm	UL-Style 1213, Unstripped
MP008853	3912316 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 4 W 1.8 A 3.5 V 8.8 mm x 8.8 mm x 2.4 mm	Each	1+ 170,280 lei 3+ 158,390 lei 10+ 148,080 lei 25+ 141,880 lei	Min.: 1 / Mult.: 1	-	1 Stage	4W	-	1.8A	3.5V	8.8mm	8.8mm	2.4mm	67°C	Multicomp Pro Peltier Module	-	UL-Style 1569, PVC Insulated
MP008857	3912320 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 36 W 3.8 A 14.7 V 30 mm x 30 mm x 3.3 mm	Each	1+ 153,920 lei 3+ 131,620 lei 10+ 119,480 lei 25+ 108,100 lei 100+ 103,230 lei	Min.: 1 / Mult.: 1	-	1 Stage	36W	-	3.8A	14.7VDC	30mm	30mm	3.3mm	66°C	-	-	100mm, UL-Style 1569, PVC Insulated
MCPF-071-14-11	1639758 Data Sheet RoHS	MULTICOMP PRO Peltier Cooler 44W	Each	1+ 177,800 lei 3+ 165,400 lei 10+ 154,640 lei 25+ 148,180 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	44W	44W	8.5A	8.8VDC	30mm	30mm	3.8mm	70°C	MCPF	0.86ohm	UL-Style 1569, Unstripped
MCPF-161-12-10-E	1639764 Data Sheet RoHS	MULTICOMP PRO Peltier Cooler 83W	Each	1+ 259,590 lei 3+ 241,450 lei 10+ 225,700 lei 25+ 216,310 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	83W	83W	6.7A	20VDC	40mm	40mm	3.3mm	71°C	MCPF	2.44ohm	UL-Style 1569, Unstripped
APHC-03104-S	2484937 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 9 W 3.7 A 3.6 VDC 16mm x 16mm x 3.6mm	Each	1+ 184,450 lei 5+ 158,090 lei 10+ 145,640 lei 20+ 125,780 lei 50+ 123,240 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	9W	9W	3.7A	3.6VDC	16mm	16mm	3.6mm	65°C	APHC	0.8ohm	100mm, UL-Style 1569, Unstripped
APHM-127-05-15	2519559 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 7.4 W 0.8 A 15.5 VDC 15mm x 15mm x 3mm	Each	1+ 389,030 lei 5+ 309,470 lei 10+ 303,280 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	7.4W	7.4W	800mA	15.5VDC	15mm	15mm	3mm	74°C	APHC	-	100mm, UL-Style 1569, Unstripped
APH-161-12-14-E	2466905 Data Sheet RoHS	EUROPEAN THERMODYNAMICS Thermoelectric Peltier Cooler Module Single Stage 56.3 W 5.1 A 19.5 VDC 40mm x 40mm x 3.7mm	Each	1+ 234,950 lei 5+ 197,870 lei 10+ 170,890 lei 20+ 167,490 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	1 Stage	56.3W	56.3W	5.1A	19.5VDC	40mm	40mm	3.7mm	69°C	APH	-	350mm, UL-Style 1569, Unstripped
MPETH-127-10-13-S	3262148 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Single Stage 35.2 W 3.9 A 15.7 VDC 30mm x 30mm x 3.6mm	Each	1+ 179,480 lei 3+ 166,980 lei 10+ 156,110 lei 25+ 149,610 lei	Min.: 1 / Mult.: 1	-	1 Stage	35.2W	-	3.9A	15.7VDC	30mm	30mm	3.6mm	74°C	MPETH	-	UL-Style 1569, Unstripped
MPDT-AR-030-2A	3267533 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Assembly Direct To Air 21 W 5 A 12 V 135mm x 105mm x 85mm	Each	1+ 317,200 lei 3+ 297,790 lei 10+ 265,280 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	-	21W	21W	5A	12VDC	135mm	105mm	85mm	-	DT-AR	-	-
MPDT-AR-024-12	3267537 Data Sheet RoHS	MULTICOMP PRO Thermoelectric Peltier Cooler Module Assembly Direct To Air 24.9 W 2.3 A 80mm x 63.3mm x 60mm	Each	1+ 774,750 lei	Min.: 1 / Mult.: 1	Thermoelectric Cooler	-	24.9W	24.9W	2.3A	15VDC	80mm	63.3mm	60mm	-	DT-AR	-	-
