LAS 50-TP
Current Transducer, LAS Series, 50A, -150A to 150A, 1 %, Voltage Output, 4.75 Vdc to 5.25 Vdc
Aveți nevoie de mai mult?
| Cantitate | Preț (fără TVA) |
|---|---|
| 1+ | 163,580 lei |
| 5+ | 160,320 lei |
| 10+ | 157,020 lei |
| 25+ | 153,770 lei |
| 50+ | 150,470 lei |
Detalii tehnice
Prezentare generală a produsului
The LAS 50-TP is a Current Transducer with isolated plastic case construction. The LAS series current transducer features as an electronic measurement of currents DC, AC, pulsed, mixed with a galvanic isolation between the primary circuit (high power) and the secondary circuit (electronic circuit). It is used for AC variable speed and servo motor drives, static converters for DC motor drives, battery supplies, uninterruptible power supplies (UPS), switched mode power supplies (SMPS) and power supplies for welding applications.
- Unipolar voltage supply
- Compact design for PCB mounting
- Excellent accuracy
- Very good linearity
- Very low temperature drift
- Wide frequency bandwidth
- No insertion losses
- High immunity to external interference
- UL94V-0 Flammability rating
Aplicaţii
Sensing & Instrumentation, Motor Drive & Control, Power Management, Industrial
Specificaţii tehnice
Voltage
5V
5.25V
1%
Eta
500ns
Through Hole
85°C
No SVHC (27-Jun-2024)
4.75V
AC / DC / Pulsed
-150A to 150A
-150A to 150A
50A
1%
-40°C
LAS Series
Documentaţie tehnică (3)
Legislaţie şi reglementări privind protecţia mediului
Tara in care ultimul proces semnificativ de fabricare a fost efectuatŢara de origine:Bulgaria
Tara in care ultimul proces semnificativ de fabricare a fost efectuat
RoHS
RoHS
Certificat de conformitate produs
