SRP200F
Battery Strap PTC, PolySwitch SRP, 30 VDC, 2 A, 4.4 A, 4 s, 100 A
2.000 Vă puteți rezerva stocul acum
| Cantitate | Preț (fără TVA) |
|---|---|
| 1+ | 3,750 lei |
| 50+ | 2,690 lei |
| 100+ | 2,580 lei |
| 250+ | 2,460 lei |
| 500+ | 2,270 lei |
| 1000+ | 2,100 lei |
Detalii tehnice
Prezentare generală a produsului
The SRP200F is a 2A PolySwitch Resettable Device with quarter-hard nickel leads and polyester tape. Raychem Circuit Protection, pioneer of polymeric PTC resettable device has developed several material platforms specifically tailored to help protect battery applications. Each of these material platforms offers different performance characteristics, allowing the engineer greater design flexibility. This SRP battery protector is compatible with high-volume electronics assembly and assists in meeting regulatory requirements. This resettable device increases battery operating time.
- Fast time-to-trip
- Low resistance devices increase battery operating time
Aplicaţii
Power Management, Portable Devices, Communications & Networking, Consumer Electronics
Avertismente
Intended for protection against occasional over-current or over-temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated.
Specificaţii tehnice
Strap
30VDC
4.4A
100A
85°C
PolySwitch SRP
2A
4s
-40°C
-
Documentaţie tehnică (2)
Alternative pentru SRP200F
1 produs găsit
Produse asociate
1 produs găsit
Legislaţie şi reglementări privind protecţia mediului
Tara in care ultimul proces semnificativ de fabricare a fost efectuatŢara de origine:China
Tara in care ultimul proces semnificativ de fabricare a fost efectuat
RoHS
RoHS
Certificat de conformitate produs
